Ceramic Multiplexers
Ceramic multiplexers support more than the two frequency bands of a duplexer. Multiplexers with custom band combinations, including overlapping bands, can be designed and manufactured to meet your specifications.
Ceramic Multiplexers
| wdt_ID | Part Number | Type | Number of Bands | Passband Frequency Ranges | I.L. in BW (dB)(max) | Ripple (dB)(max) | R.L. (dB)(min) | Attenuation at Reject Band (db)(min) | Isolation (dB)(min) | Power | Dimensions | Connector Type | Keep this part? | Data sheet exists? | Band Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | MCX3-000001A1 | Ceramic | 3 | 935~960 1805~1880 2110~2170 |
1.50 | 0.50 | 18 | 20 | 10 | 52x33x20 | SMA-f | Convert | Y | ||
| 2 | MPM3-000001A1 | Ceramic | 3 | 698~716 728~757 776~787 |
3.90 | 1.50 | 15 | 30 | 2 | 90x34x10 | Y | LTE | |||
| 3 | MPX3-000001A1 | Ceramic | 3 | 973~983 1085~1095 1025~1035 |
3.00 | 1.00 | 14 | 42 | 3 | 45x22x6 | Y | UHF L-Band | |||
| 4 | MPX3-000002A1 | Ceramic | 3 | 925~960 1805~1880 2110~2170 |
1.50 | 0.50 | 18 | 20 | 3 | 34x25x6 | Convert | Y | |||
| 5 | MPX3-000003A1 | Ceramic | 3 | 935~960 1805~1880 2110~2170 |
1.50 | 0.50 | 18 | 20 | 3 | 34x25x6 | Convert | Y | |||
| 6 | MPX-000004A1 | Ceramic | 3 | 300~800 1000~1500 1800~2300 |
2.70 | 1.50 | 12 | 20 | 3 | 70x60x12 | Convert | Y | L-Band S-Band C-Band | ||
| 7 | MPX3-000006A1 | Ceramic | 3 | 1430~1850 2185~2485 4400~5400 |
2.00 | 1.20 | 2 | 25 | 1 | 47x40x6.5 | Y | L-Band S-Band C-Band | |||
| 8 | MPX3-000007A1 | Ceramic | 3 | 2305~2315 2350~2360 2500~2700 |
2.50 | 1.00 | 15 | 40 | 40 | 6 | 55x35x9.5 | Y | LTE WCS | ||
| 9 | MPX4-000001A1 | Ceramic | 4 | 851~966 1805~1955 2110~2170 2300~2620 |
2.70 | 1.00 | 12 | 30 | 3 | 70x30x5 | Y | UHF L-Band S-Band | |||
| 10 | MPX4-000002A1 | Ceramic | 4 | 824~849 882~922 1710~1785 1920~1980 |
4.50 | 2.00 | 15 | 20 | 55 | 10 | 110x60x10 | Y | CELL GSM DCS UMTS | ||
| 11 | MPX4-000003A1 | Ceramic | 4 | 1850~1915 1930~1995 1710~1755 2110~2155 |
5.30 | 3.10 | 15 | 60 | 3 | 108x30x9.3 | Convert | Y | |||
| 12 | MPX4-000004A1 | Ceramic | 4 | 800~900 1565~1585 1616~1626.5 2400~2500 |
5.50 | 2.50 | 15 | 30 | 30 | 1 | 76.2x63.5x25.4 | Y | GSM GPS WiFi Iridium | ||
| 13 | MPX4-000005A1 | Ceramic | 4 | 1746.7~1766.7 1960~1980 1841.7~1861.7 2150~2170 |
2.00 | 14 | 10 | 10 | 100x55 | ||||||
| 14 | MPX4-000006A1 | Ceramic | 4 | 1850~1910 1930~1990 824~849 869~894 |
1.50 | 18 | 75 | 50 | 142x142x103 | Y | LTE band-2 LTE band-5 | ||||
| 15 | MPX4-000007A1 | Ceramic | 4 | 1709.5~1784.5 1805~1880 880~915 925~960 |
1.50 | 18 | 75 | 50 | 166.0x112.0x88.0 | Y | LTE band-3 | ||||
| 16 | MPX5-000001A1 | Ceramic | 5 | 698~716 728~757 777~787 817~849 862~894 |
4.20 | 1.70 | 17 | 40 | 50 | 3 | 130x65x11.5 | Convert | Y | ||
| Number of Bands | Power | Band Type |
