Ceramic Monoblock & Ceramic Waveguide Triplexers
Triplexers enable three distinct frequency bands to share a single antenna or transmission path, providing compact, cost-effective multi-band operation with minimal loss and excellent isolation. MCV offers two advanced triplexer solutions—Ceramic Monoblock and Ceramic Waveguide—each optimized for different installation, size, and performance requirements.
Ceramic Monoblock Triplexers
-
Compact, All-In-One Design: Precision-machined ceramic resonators are integrated into a single monolithic block, delivering stable frequency response without the need for separate discrete filters.
-
Low Insertion Loss & High Isolation: Monoblock construction minimizes parasitic effects, achieving insertion loss <1.0 dB per band and inter-band isolation >50 dB.
-
Broadband Capability: Standard models cover combinations such as 700/850/1900 MHz or 2.1/2.3/2.6 GHz; custom bandplans available on request.
-
Rugged Surface-Mount Package: Ideal for space-constrained and mass-production applications in small cells, Wi-Fi access points, and compact base stations.
Ceramic Waveguide Triplexers
-
Waveguide-Enhanced Performance: Ceramic resonators coupled into a precision waveguide manifold deliver exceptionally sharp filter skirts and power handling up to 200 W CW.
-
Ultra-High Isolation & Power Handling: Insertion loss <0.7 dB, isolation >60 dB, and PIM performance better than –160 dBc, ensuring clean multi-band operation in high-density RF environments.
-
Connectorized Enclosure: Robust, flange-mount waveguide package simplifies integration into outdoor radio heads, DAS head-ends, and mission-critical communications.
-
Extended Frequency Ranges: Typical bandplans include 700/850/1900 MHz or 3.4/3.6/3.8 GHz, with custom configurations up to 6 GHz.
Applications
-
Small-cell and macro-cell base stations
-
Distributed Antenna Systems (DAS)
-
In-building wireless coverage
-
Public safety and mission-critical networks
Whether your design calls for ultra-compact surface-mount integration or high-power waveguide performance, MCV’s Ceramic Monoblock and Ceramic Waveguide Triplexers deliver the multi-band functionality, reliability, and RF purity your system demands.
